Fully automatic board planting machine PX-350

Functional features

CCD scanning can achieve the integration of three codes, and the quality can be traced.

Ccd-assisted precise positioning vehicles and products are of guaranteed quality.

Automatic vehicle cleaning function;

Rapid vehicle replacement enables quick change of material numbers.

The equipment can be optionally equipped with AGV automatic feeding, etc

Specification parameters

Device dimensions: 1580*1200*1525(L*W*H), excluding display and lamp

Product size:

MAX: 300mm*250mm

Min: 250mm*100mm

Working dimensions: 300mm*250mm

Equipment accuracy: ±0.1mm

Feeding height: 900mm±20

Incoming material method: Tray/Kraft paper stacking/left in and right out

Air pressure: >0.5kpa

Electrical specification: 220V

Weight: ≤1000kg

CT: 16S
