This equipment is used for the mounting of large-sized automotive components in the FPC manufacturing process.
This equipment is used for the mounting of large-sized automotive components in the FPC manufacturing process.
Features:
/ Automotive component placement
/ Segmented placement
/ Independent bottom heating and support
Specifications:
/ Working area (mm): 550 x 330
/ Material dimensions (mm): 3 x 3 to 60 x 150; 3-inch and 6-inch formats
/ Carrier dimensions (mm): 1200 x 400
/ Placement head: Single head with dual nozzles
/ Compatible materials: Large-format PI, adhesive tape, FR4
/ Equipment precision: 0.02 mm
/ Placement accuracy/efficiency:
4-point Mark high-speed mode: ±0.15 mm, 1.2 s/pc (excluding material expansion/shrinkage)
Single-point alignment high-precision mode: ±0.075 mm, 1.5 s/pc
/ Transport method: Rail + carrier
/ Feeding method: Roll-fed peeling feeder
/ Power consumption/supply: AC 220V / 4.5 kW
/ Air pressure: 0.6 MPa
/ Weight (kg): 1000
/ Dimensions (mm) (L x W x H): 1550 x 1160 x 1680
