20T punch press connection line

Functional features

The PUNCH power system output is made by using an 11KW servo motor

The stroke can be digitally set and precisely positioned

Multiple types of mold installation methods

Automatic loading and unloading by mechanical hand (single configuration) or automatic loading and unloading (double configuration)

It can be used in conjunction with multiple units online or in combination with other FPC production equipment for online connection.

Optional connection to the Mes system is available to bind product, work order, mold and other information.

Optional functions such as CCD mold inspection can be added.

Specification parameters

Equipment dimensions: 1570mm*1630*1670mm(L*W*H)

Cutting force: ≥ 20Tons

Mold size:

310mm(width)*180mm,200mm,250mm,360mm

360mm(width)* 180mm,200mm,250mm,360mm

Blanking depth adjustment accuracy: ±0.02mm

Machine working height: 1050±20mm

/Board entry direction: Left entry and right exit

Electrical specification: 220V

Air pressure: 0.5 to 0.7MPa

CT: 8 seconds /Punch(excluding the single punching time for loading and unloading)

Working dimensions: 360mm - 360mm
